Plano 3.0 Space
Type
Color
- Black RAL 9005, White RAL 9016, On request
Plano 3.0 Space differs from the standard Plano 3.0 model through the use of reflector optics, providing focused light output and enhanced visual comfort for customers. The luminaire allows several optical types to be combined within a single housing, enabling multiple lighting tasks to be addressed within one project. Thanks to its high output, the number of luminaires required can be reduced while maintaining the desired lighting level.
Application area
There are various applications for this luminaire, such as shopping malls, showrooms, offices, and administrative premises. Also, this lamp will be ideally suited for small rooms.
Specification
- Luminaire type Linear Light
- Application areas General and accent lighting
- Luminous flux class 3000 lm - 7500 lm
- Light color 3000 K, 3500 K, 4000 K
- CRI 80
- Beam angle 90°
- Tilt angle 18°
- Certifications UA, CE, UKCA
- Life time 50,000 hours (L80B10)
- Warranty 5 years / 50,000 hours
Materials
- Body Aluminium
- Optical element PC
- Weight 2.5 kg
Electrical equipment
- Power supply LED driver (DALI on request)
- Lighting technology LED SMD 2835
- Input voltage 230 V, 50 Hz
- Cooling Passive
- Power factor 0.95
Mounting type
- Mounting 3P track mounting (3PH)
